1 1/2″ x 1″ TLV GT14L Cast Iron Mechanical Pump Trap
Main body elements made of cast iron FC250
PN16 Flanged ends to BS EN 1092-1 on 1 1/2″ inlet & 1″ outlet for pumped medium
1/2″ BSP threaded motive inlet, for use with saturated steam
1/2″ BSP threaded pump exhaust port/outlet
Compact pump design allows for installation in confined spaces
Built-in stainless steel steam trap
Built-in stainless steel check valves on inlet & outlet ports for pumped medium (Inlet: CKF5M x Outlet: CKF3M)
Can handle high-temperature steam condensate without cavitation
No electrical supply or additional controls required making the GT14L intrinsically safe
Pump will operate with a low filling-head (Minimum: 300mm)
High quality stainless steel internals with inline access guarantee easy cleaning and maintenance as well as a long service life
Ideal for a range of applications including drainage of heat exchangers, flash steam recovery systems and reservoirs, often operating under vacuum conditions
Pump discharge capacity: Up to approx. 2200 kg/h (2.2 t/h)
Maximum operating pressure (motive): 13 bar
Maximum operating temperature: 200°C
