2″ Genebre Art5640 3-Way L-Port Stainless Steel Actuated Ball Valve (Electric Actuator)

SKU: 81ART5640-09-52
Availability:In stock (can be backordered)

£622.02 ex. VAT

In stock (can be backordered)

About this product

2″ Genebre Art5640 Stainless Steel 3-Way L-Port Stainless Steel Ball Valve Fitted With an Electric Actuator

Genebre Art2040 ball valve with an electric actuator

3-Way reduced bore ball valve with an “L-ported” ball configuration

Female BSPT taper threaded ends conforming to ISO 7-1 (BS EN 10226-1)

Made of stainless steel 1.4408 (CF8M)

Ball seats made of PTFE & 15% graphite

PTFE stem gasket

Stem O-ring made of FPM (Viton)

Anti-static device ensures continuity between the ball, body & stem which is required when used with flammable mediums

Direct actuator mount conforming to ISO 5211 (F-05/F-07 x 14mm)

Blow-out proof stem

Maximum operating pressure: 63 bar (PN63)

Operating temperature range: -25°C – 180°C

Comes with a factory fitted GE-1 electric rotary actuator

Actuator electrical supply voltages: 24 – 240 VDC/VAC (50/60Hz)

Actuator electrical supply connections: DIN EN 175301-803

Required voltage must be specified at time of purchase

Specification

Weight 7.3 kg
Dimensions 200 × 316 × 129 mm
Valve Size

2" NB
