Albion Art59 DZR Brass Ball Valve (Compression Fit)

Brand: Albion
SKU: 31ART59

£5.62£57.86 ex. VAT

About this product

Albion Art59 Full Bore DZR Brass Ball Valve (Compression Fit)

Full bore ball valve with DZR (Dezincification resistant) brass body

Compression fitting ends to BS EN 1254-2 with brass nuts & compression olives/ferrules

Chrome plated brass ball with PTFE ball seats

Anti blow-out stem in brass with PTFE stem packing & NBR O-ring

WRAS approved for use with drinking/potable water

<

Manual operation via lever handle, suitable for use with locking levers

Maximum operating pressure: 25 bar (PN25) at up to 110°C

Operating temperature range: -10°C – 110°C

Specification

Weight N/A
Dimensions N/A
Brand

Valve Type

2-Piece Full Bore Ball Valve

Connections

Compression Fit – BS EN 1254-2

Operation

Manual Lever/Handle Operated

Body Material

DZR (Dezincification resistant) Brass

Ball Material

Brass (Chrome Plated)

Stem Material

Brass

Ball Seat Material

PTFE

Stem Packing Material

NBR

Maximum Operating Pressure

25 bar

Operating Temperature Range

-10°C – 110°C

Approvals

WRAS Approved (Potable water).

Additional Information

Suitable for locking levers

Certification Availability

N/A
