Albion Art88 Reduced Bore 3-Way Brass Ball Valve (L-Port)

Brand: Albion
SKU: 31ART88

£80.21£656.49 ex. VAT

About this product

Albion Art88 Reduced Bore 3-Way Direct Mount Brass Ball Valve (L-Port)

Reduced bore 3-way ball valve with an L-ported ball configuration

Full body made of chrome plated brass

Female BSPP parallel threaded ends conforming to ISO 228/1

Chrome plated brass ball with PTFE ball seats/seals

Nickel plated brass stem with FKM rubber (Viton) O-ring

CE approved

Comes with a ISO 5211 direct mount bracket for installing an actuator

Lever handles available seperately

Valve torque at zero pressure: See datasheet

Maximum operating pressure: 30 bar (PN30) at up to 90°C

Operating temperature range: -20°C – 120°C

Specification

Weight N/A
Dimensions N/A
Brand

Valve Type

Reduced Bore 3-Way Ball Valve (L-Port)

Connections

Female BSPP Parallel Threads – ISO 228-1, BS EN 10226-1

Body Material

Brass (Chrome Plated)

Ball Material

Brass (Chrome Plated)

Stem Material

Brass (Nickel Plated)

Ball Seat Material

PTFE

Stem O-Ring Material

FKM

Maximum Operating Pressure

20 bar

Operating Temperature Range

-20°C – 120°C

Approvals

CE Marked (Quality).

Certification Availability

N/A
