TLV SCOS-16 Compact Bronze Pressure Reducing Valve
Main body elements made of bronze
Female BSPT taper threaded ends to DIN 2999
Compact and lightweight design allows for installation in confined spaces
Built-in cyclone separator and free float steam trap removes up to 98% of condensate
Easy pressure adjustment using the top-mounted adjustment screw/handle
Self-aligning, shock absorbing spherical piston and advanced pilot regulator designs maintain secondary steam pressure accuracy, even during adverse process conditions
All major internal components are made of stainless steel, preventing rust and corrosion for a long service life
Stainless steel filter screen protects valve components for trouble-free operation and a longer service life
Internal secondary pressure sensing channel makes external sensing lines unnecessary
Trap discharge capacity: Up to 80kg/h
Maximum operating pressure: 16 bar
Maximum operating temperature: 220°C
