1 1/2″ x 1″ TLV GP14L Cast Iron Mechanical Pump (PN25/40 Flanged)

Brand: TLV
SKU: 76GP14L040
Availability:In stock (can be backordered)

£4,529.00 ex. VAT

In stock (can be backordered)

About this product

1 1/2″ x 1″ TLV GP14L Cast Iron Mechanical Pump (PN25/40 Flanged)

Body made of cast iron FC250

PN25/PN40 Flanged ends to DIN 2501 (BS EN 1092-1)

Built-in stainless steel check valves on condensate inlet & outlet (Inlet: CKF5M x Outlet: CKF3M)

Handles high temperature condensate without cavitation

No electrical supply or additional controls required making the GP14L intrinsically safe

Can operate with a low filling head (minimum 300mm)

Inline access to internal parts simplifies cleaning and maintenance, also reduces downtime

High-quality, hardened stainless steel working surfaces guarantee a long service life

Compact pump design allows for installation in confined spaces

Suitable for pumping steam condensate or water

1/2″ Motive medium inlet, suitable for saturated steam, compressed air and nitrogen

Cycle counter can be installed as an optional extra

Discharge capacity: Up to approx. 2400 kg/h

Maximum operating pressure: 14 bar

Maximum operating temperature: 220°C

Specification

Weight 55 kg
Dimensions 360 × 410 × 350 mm
Valve Size

1 1/2" x 1" NB

Brand

Valve Type

Condensate Recovery Pump

Connections

PN25/PN40 Flanged (BS EN 1092-1)

Body Material

Cast Iron FC250

Float Material

Stainless Steel 316

Body Gasket Material

Graphite Compound

Maximum Operating Pressure

13 bar

Motive Medium Pressure Range

0.3 – 13 bar

Operating Temperature Range

0°C – 200°C

Maximum Discharge Capacity

Up to 2400kg/h (2.4t/h)

Additional Information

1/2" BSP Motive medium inlet & exhaust outlet. Built-in check valves on condensate inlet & outlet. Intrinsically safe. Can operate with low filling head.

Certification Availability

Contact Us (Chargeable, may increase delivery time.)
