Genebre Art2231 Carbon Steel Bellows Sealed Globe Valve (PN16 Flanged)
Suitable for use in installations such as thermal oil plants, steam and high temperature fluids in general as well as vacuum systems
Manual operation globe/stop valve conforming to BS EN 13709:2010 (DIN 3356) with a bellows sealed stem
PN16 flanged ends conforming to BS EN 1092-1:2018
Valve body and bonnet made of painted carbon steel 1.0619 (WCB) sealed with a stainless steel 304 & graphite gasket
Non-rising stainless steel 304 stem with graphite stem pack and SS304 bellows which completely prevent leakage
Face to face flange dimensions conform to BS EN 558 S1 (DIN 3202 F1)
Flange diameter: 95mm
Flange pitch circle diameter (PCD): See datasheet
Bolt holes: See datasheet
Metal seat and disc with stainless steel welding
Grease nipple for lubrication of stem bushes
Position indicator
Built-in painted carbon steel handwheel for valve operation
Maximum operating pressure: 16 bar (PN16) at up to 120°C
Operating temperature range: -20°C – 350°C
