Albion Art400 EPDM Rubber Expansion Bellows

Brand: Albion
SKU: 31ART400

£17.23£59.25 ex. VAT

About this product

Albion Art400 PN16 Screwed Flexible EPDM Expansion Bellows

The ART 400 is a durable and versatile flexible connector with an EPDM bellow reinforced by nylon cord and steel for enhanced strength. It features galvanized malleable iron union ends with female BSPT taper threads conforming to ISO 7/1 standards. Designed to absorb movement and vibration, it maintains reliable performance in demanding applications, with a PN16 pressure rating and an operating temperature range of -20°C to 100°C.

Key Features:

  • Female BSPT taper threaded ends to ISO 7/1
  • EPDM flexible bellows with nylon cord reinforcement
  • Galvanized malleable iron union ends
  • PN16 pressure rated, temp range: -20°C to 100°C

Specification

Weight N/A
Dimensions N/A
Brand

Valve Type

Expansion Bellows

Connections

Female BSPT Taper Threads – ISO 7-1, BS EN 10226-1

Body Material

EPDM + Nylon (Bellows). Galvanised Malleable Iron (Union Ends)

Body Gasket

Steel Wire

Maximum Operating Pressure

16 bar

Operating Temperature Range

-20°C – 100°C

Certification Availability

N/A
